IS620P User Manual Chapter 7 Function Code Table
- 165 -
Group H03: Input Terminal Parameters
Function
Code
Parameter
Name
Setting Range Unit Default
Effective
Time
Property
Control
Mode
H03 00
Function
allocation 1 of
DIs that are
set to ON and
effective
0–0xFFFF
Bit0: FunIN.1
Bit1: FunIN.2
……
Bit15: FunIN.16
- 0
Power-on
again
During
running
-
H03 01
Function
allocation 2 of
DIs that are
set to ON and
effective
0–0xFFFF
Bit0: FunIN.17
Bit1: FunIN.18
……
Bit15: FunIN.32
- 0
Power-on
again
During
running
-
H03 02
DI1 function
selection
0–37 - 14 Upon stop
During
running
-
H03 03
DI1 logic
selection
Input polarity: 0–4
0: Low level active
1: High level active
2: Rising edge active
3: Falling edge active
4: Both rising edge and
falling edge active
- 0 Upon stop
During
running
-
H03 04
DI2 function
selection
0–37 - 15 Upon stop
During
running
-
H03 05
DI2 logic
selection
Input polarity: 0–4
0: Low level active
1: High level active
2: Rising edge active
3: Falling edge active
4: Both rising edge and
falling edge active
- 0 Upon stop
During
running
-
H03 06
DI3 function
selection
0–37 - 13 Upon stop
During
running
-
H03 07
DI3 logic
selection
Input polarity: 0–4
0: Low level active
1: High level active
2: Rising edge active
3: Falling edge active
4: Both rising edge and
falling edge active
- 0 Upon stop
During
running
-
H03 08
DI4 function
selection
0–37 - 2 Upon stop
During
running
-
