Group H07: Torque Control Parameters
100% of the torque reference corresponds to the rated motor torque.
Function
Code
Parameter
Name
Setting Range Unit Default
Effective
Time
Property
Control
Mode
H07 00
Main torque
reference A
source
0: Digital setting (H07-03)
1: AI1
2: AI2
- 0 Immediate At stop T
H07 01
Auxiliary
torque
reference B
source
0: Digital setting (H07-03)
1: AI1
2: AI2
- 1 Immediate At stop T
H07 02
Torque
reference
source
0–3 - 0 Immediate At stop T
H07 03
Keypad setting
value of torque
reference
-300.0 to 300.0 % 0 Immediate
During
running
T
H07 05
Torque
reference lter
time constant 1
0–30.00 ms 0.79 Immediate
During
running
PST
H07 06
Torque
reference lter
time constant 2
0–30.00 ms ms 0.79 Immediate
During
running
PST
H07 07
Torque limit
source
0: Internal
1: External setting (P-CL
and N-CL selection)
2: External T-LMT setting
3: Smaller of external
setting and external
T-LMT setting (P-CL and
N-CL selection)
4: Switchover between
internal setting and T-LMT
setting
1 0 Immediate At stop PST
H07 08
T-LMT
selection
1: AI1
2: AI2
1 2 Immediate At stop PST
H07 09
Internal
forward torque
limit
0.0–300.0 % 300.0 Immediate
During
running
PST
H07 10
Internal
reverse torque
limit
0.0–300.0
% 300.0 Immediate
During
running
PST
H07 11
External
forward torque
limit
0.0–300.0 % 300.0 Immediate
During
running
PST
