Chapter 2 Mounting Dimensions of Servo System IS620P User Manual
- 22 -
2. Cooling
As shown in the above gure, keep sufcient clearances around the servo drive to ensure
cooling by cooling fans or natural convection. Install cooling fans above the servo drive
to avoid excessive temperature rise and maintain even temperature inside the control
cabinet.
3. Installation side by side
When installing multiple servo drives side by side, keep at least 10 mm between two servo
drives (if installation space is limited, such clearance between servo drives can be ignored)
and at least 50 mm above and below each servo drive.
4. Grounding
The grounding terminal must be properly grounded. Failure to comply may cause electric
shock or malfunction due to interference.
2.3 Mounting Dimensions of the Servo Motor
2.3.1 Mounting Dimensions of the ISMH1 Series Z Motor
1) 100 W (Vn = 3000 RPM, Vmax = 5000 RPM)
LL
LG
2.5
25
16
12
24
0.04
A
15.5
A
0.02
0
500
10
500
8
-0.009
φ
0.04
A
φ
30
0
-0.021
φ
40
22
46
φ
4.5
φ
TP
x 2
6.2
-0.1
0
0.01 A
Shaft end
3
-0.029
-0.004
3
-0.014
0
3
-0.014
0
Flat key
