Inovance IS620P Series User Manual

IS620P User Manual Chapter 7 Function Code Table
- 203 -
Function
Code
Parameter
Name
Setting Range Unit Default
Effective
Time
Property
Control
Mode
H12 64
Acceleration/
Deceleration
time of 15th
speed reference
0: No acceleration/
deceleration time
1: Acceleration/
Deceleration time 1
2: Acceleration/
Deceleration time 2
3: Acceleration/
Deceleration time 3
4: Acceleration/
Deceleration time 4
- 0 Immediate At stop S
H12 65
16th speed
reference
-6000 to 6000 rpm -300 Immediate At stop S
H12 66
Running time
of 16th speed
reference
0–6553.5
s
(min)
5.0) Immediate At stop S
H12 67
Acceleration/
Deceleration
time of 16th
speed reference
0: No acceleration/
deceleration time
1: Acceleration/
Deceleration time 1
2: Acceleration/
Deceleration time 2
3: Acceleration/
Deceleration time 3
4: Acceleration/
Deceleration time 4
- 0 Immediate At stop S
Group H17: VDI/VDO Parameters
Function
Code
Parameter
Name
Setting Range Unit Default
Effective
Time
Property
Control
Mode
H17 00
VDI1
function
selection
0–37 - 0
Upon
stop
During
running
-
H17 01
VDI1 logic
selection
0: Active when the written value
is 11
1: Inactive when the written
value changes from 0 to 1
- 0
Upon
stop
During
running
-
H17 02
VDI2
function
selection
0–37 - 0
Upon
stop
During
running
-
H17 03
VDI2 logic
selection
0: Valid when the written value
is 1
1: Inactive when the written
value changes from 0 to 1
- 0
Upon
stop
During
running
-
H17 04
VDI3
function
selection
0–37 - 0
Upon
stop
During
running
-
