5.3.2.2.6 PCI Screen
The PCI Screen allows the user to configure the PCI add-in cards, onboard NIC controllers, and
video options.
To access this screen from the Main screen, select Advanced > PCI.
Advanced
PCI Configuration
Maximize Memory below 4GB Enabled/Disabled
Memory Mapped I/O above 4GB Enabled/Disabled
Onboard Video Enabled/Disabled
Dual Monitor Video Enabled/Disabled
Onboard NIC1 ROM Enabled/Disabled
Onboard NIC2 ROM Enabled/Disabled
Onboard NIC iSCSI ROM Enabled/Disabled
NIC 1 MAC Address <MAC #>
NIC 2 MAC Address <MAC #>
Figure 36. Setup Utility — PCI Configuration Screen Display
Table 29. Setup Utility — PCI Configuration Screen Fields
Setup Item Options Help Text Comments
Maximize Memory
below 4GB
Enabled
Disabled
BIOS maximizes memory usage below 4GB for
an OS without PAE support, depending on the
system configuration. Only enable for an OS
without PAE support
Memory Mapped I/O
above 4GB
Enabled
Disabled
Enable or disable memory mapped I/O of 64-bit
PCI devices to 4 GB or greater address space.
Onboard Video
Enabled
Disabled
Onboard video controller.
Warning: System video is completely disabled if
this option is disabled and an add-in video
adapter is not installed.
When disabled, the system
requires an add-in video
card for the video to be
seen.
Dual Monitor Video Enabled
Disabled
If enabled. both the onboard video controller and
an add-in video adapter are enabled for system
video. The onboard video controller becomes the
primary video device.
Onboard NIC1 ROM
Enabled
Disabled
If enabled. loads the embedded option ROM for
the onboard network controllers.
Warning: If [Disabled] is selected, NIC1 cannot be
used to boot or wake the system.
Onboard NIC2 ROM
Enabled
Disabled
If enabled. loads the embedded option ROM for
the onboard network controllers.
Warning: If [Disabled] is selected, NIC2 cannot be
used to boot or wake the system.
