Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS Functional Architecture
Revision 1.8
Intel order number E39529-013
37
Table 5. Supported DIMM Population under the Dual Processors Configuration
# N
CPU1 Socket = Populated CPU2 Socket = Populated
M
A1 A2 B1 B2 C1 C2 D1 D2 E1 E2 F1 F2
1 1 X N
2 2 X X N
3 2 X X N
4 2 X X N
5 3 X X X N
6 3 X X X N
7 3 X X X N
8 4 X X X X N
9 4 X X X X Y
10 6 X X X X X X Y
11 6 X X X X X X N
12 7 X X X X X X X N
13 8 X X X X X X X X Y
14 8 X X X X X X X X N
15 9 X X X X X X X X X N
16 12 X X X X X X X X X X X X N
Table 6. Supported DIMM Population under the Single Processor Configuration
# N
CPU1 Socket = Populated CPU2 Socket = Empty
M
A1 A2 B1 B2 C1 C2 D1 D2 E1 E2 F1 F2
1 1 X N
2 2 X X N
3 2 X X Y
4 3 X X X N
5 4 X X X X N
6 4 X X X X Y
7 6 X X X X X X N
Note: The generic principles and guidelines described in the above sections also apply to the
above two tables.
