Intel® Server Boards S5520HC, S5500HCV and S5520HCT TPS Appendix B: Compatible Intel® Server Chassis
Revision 1.8
Intel order number E39529-013
147
Appendix B: Compatible Intel
®
Server Chassis
Refer to the following table for the compatible Intel
®
Server Chassis of Intel
®
Server Boards S5520HC, S5500HCV and S5520HCT:
Passive tower processor heatsink(s) (product code: FXXRGTHSINK) is required when installing the Intel
®
Server Board S5520HC or
S5500HCV in the Intel
®
Server Chassis SC5600LX.
Active processor heatsink(s) is required when installing the Intel
®
Server Board S5520HC or S5500HCV in any of following Intel
®
Server Chassis:
 Intel
®
Server Chassis SC5600Base
 Intel
®
Server Chassis SC5600BRP
 Intel
®
Server Chassis SC5650DP
 Intel
®
Server Chassis SC5650BRP
Table 81. Compatible Chassis/Heatsink Matrix
S5520HC S5500HCV Chassis SKU Heatsink Includes
Intel
®
Thermal Solution
STS100C (w/ fan, Active
mode)
Intel
®
Thermal Solution
STS100A (Active)
FXXRGTHSINK
(Passive Tower Heatsink)
Y
Y
SC5600Base
No
Y Y
N
Y Y
SC5600BRP
No
Y Y
N
Y Y
SC5600LX
No N N Required
Y Y
SC5650DP
No
Y Y
N
Y Y
SC5650BRP
No
Y Y
N
Y: Support
N: Not Support
Maximum CPU
Power
Support in
Intel Server
95 W 80 W 95 W
