Functional Architecture Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
40
• Intel
®
Embedded Server RAID Technology II Option ROM
• Intel
®
Embedded Server RAID Technology II drivers, most recent revision
• At least two SATA hard disk drives
3.4.1.1.1 Intel
®
Embedded Server RAID Technology II Option ROM
The Intel
®
Embedded Server RAID Technology II for SATA Option ROM provides a pre-
operating system user interface for the Intel
®
Embedded Server RAID Technology II
implementation and provides the ability to use an Intel
®
Embedded Server RAID Technology II
volume as a boot disk and detect any faults in the Intel
®
Embedded Server RAID Technology II
volume(s).
3.4.1.2 Onboard SATA Storage Mode Matrix
Table 7. Onboard SATA Storage Mode Matrix
SW RAID = Intel
®
Embedded Server RAID Technology II (ESRTII)
Storage
Controller
Storage Mode* Description
RAID Types and
Levels Supported
Driver
RAID
Management
Software
RAID
Software
User’s Guide
Compatible
Backplane
Onboard
SATA
Controller
(ICH10R)
Enhanced
6 SATA ports at
Native mode
N/A
Chipset driver
or operating
system
embedded
Broad OS
support
N/A N/A
AXX6DRV3G
R
AXX4DRV3G
R
Compatibility
6 SATA ports:
port 0, 1, 2, 3 at
IDE Legacy
mode, port 4, 5
at Native mode
N/A
Chipset driver
or operating
system
embedded
Broad OS
support
N/A N/A
AHCI
6 SATA ports
using the
Advanced Host
Controller
Interface
N/A
AHCI driver
or OS
embedded
Broad OS
support
N/A N/A
SW RAID 6 SATA Ports
SW RAID 0/1/10
standard
SW RAID 5 with
optional
AXXRAKSW5
ESRTII Driver
Microsoft
Windows*
and selected
Linux*
Versions only
Intel
®
RAID
Web
Console 2
Intel
®
RAID
Software
User’s
Guide
* Select in BIOS Setup: “SATA Mode” Option on Advanced | Mass Storage Controller Configuration Screen
