BIOS Setup Utility Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
82
5.3.2.2.2 Memory Screen
The Memory screen allows the user to view details about the system memory DDR3 DIMMs
installed. This screen also allows the user to open the Configure Memory RAS and Performance
screen.
To access this screen from the Main screen, select Advanced > Memory.
Advanced
Memory Configuration
Total Memory <Total Physical Memory Installed in System>
Effective Memory <Total Effective Memory>
Current Configuration <Independent/Mirror>
Current Memory Speed <Speed that installed memory is running at.>
► Memory RAS and Performance Configuration
DIMM Information
DIMM_A1 Installed/Not Installed/Failed/Disabled
DIMM_A2 Installed/Not Installed/Failed/Disabled
DIMM_B1 Installed/Not Installed/Failed/Disabled
DIMM_B2 Installed/Not Installed/Failed/Disabled
DIMM_C1 Installed/Not Installed/Failed/Disabled
DIMM_C2 Installed/Not Installed/Failed/Disabled
DIMM_D1 Installed/Not Installed/Failed/Disabled
DIMM_D2 Installed/Not Installed/Failed/Disabled
DIMM_E1 Installed/Not Installed/Failed/Disabled
DIMM_E2 Installed/Not Installed/Failed/Disabled
DIMM_F1 Installed/Not Installed/Failed/Disabled
DIMM_F2 Installed/Not Installed/Failed/Disabled
Figure 31. Setup Utility — Memory Configuration Screen Display
