Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS BIOS Setup Utility
Revision 1.8
Intel order number E39529-013
97
Table 33. Setup Utility — Console Redirection Configuration Fields
Setup Item Options Help Text
Console Redirection
Disabled
Serial Port A
Serial Port B
Console redirection allows a serial port to be used for
server management tasks.
[Disabled] - No console redirection.
[Serial Port A] - Configure serial port A for console
redirection.
[Serial Port B] - Configure serial port B for console
redirection.
Enabling this option disables the display of the Quiet
Boot logo screen during POST.
Flow Control
None
RTS/CTS
Flow control is the handshake protocol.
Setting must match the remote terminal application.
[None] - Configure for no flow control.
[RTS/CTS] - Configure for hardware flow control.
Baud Rate 9600
19.2K
38.4K
57.6K
115.2K
Serial port transmission speed. Setting must match
the remote terminal application.
Terminal Type PC-ANSI
VT100
VT100+
VT-UTF8
Character formatting used for console redirection.
Setting must match the remote terminal application.
Legacy OS
Redirection
Disabled
Enabled
This option enables legacy OS redirection (i.e., DOS)
on serial port. If it is enabled, the associated serial
port is hidden from the legacy OS.
5.3.2.5 Server Management System Information Screen
The Server Management System Information screen allows the user to view part numbers,
serial numbers, and firmware revisions.
To access this screen from the Main screen, select Server Management > System
Information.
