Appendix E: POST Code Diagnostic LED Decoder Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
162
Upper nibble bits = 1110b = Eh; Lower nibble bits = 1101b = Dh; the two are
concatenated as EDh. Find the meaning of POST Code EDh in below table – Memory
Population Error: RDIMMs and UDIMMs cannot be mixed in the system.
Table 85. POST Codes and Messages
Progress Code Progress Code Definition
Multi-use Code
This POST Code is used in different contexts
0xF2
Seen at the start of Memory Reference Code (MRC)
Start of the very early platform initialization code
Very late in POST, it is the signal that the OS has switched to virtual memory mode
Memory Error Codes (Accompanied by a beep code)
These codes are used in early POST by Memory Reference Code. Later in POST these same codes are used for
other Progress Codes. These progress codes are subject to change as per Memory Reference Code
0xE8 No Usable Memory Error: No memory in the system, or SPD bad so no memory could be
detected, or all memory failed Hardware BIST. System is halted.
0xEB Memory Test Error: One or memory DIMMs/Channels failed Hardware BIST, but usable memory
remains. System continues POST.
0xED Population Error: RDIMMs and UDIMMs cannot be mixed in the system.
0xEE Mismatch Error: more than 2 Quad Ranked DIMMS in a channel.
Host Processor
0x04 Early processor initialization where system BSP is selected
0x10 Power-on initialization of the host processor (Boot Strap Processor)
0x11 Host processor cache initialization (including AP)
0x12 Starting application processor initialization
0x13 SMM initialization
Chipset
0x21 Initializing a chipset component
Memory
0x22 Reading configuration data from memory (SPD on DIMM)
0x23 Detecting presence of memory
0x24 Programming timing parameters in the memory controller
0x25 Configuring memory parameters in the memory controller
0x26 Optimizing memory controller settings
0x27 Initializing memory, such as ECC init
0x28 Testing memory
PCI Bus
0x50 Enumerating PCI buses
0x51 Allocating resources to PCI buses
0x52 Hot-plug PCI controller initialization
0x53-0x57 Reserved for PCI Bus
