BIOS Setup Utility Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
102
5.3.2.6.2 Delete Boot Option Screen
The Delete Boot Option screen allows the user to remove an EFI boot option from the boot
order. Note that while you can delete the Internal EFI Shell in this screen, it is restored to the
Boot Order on the next reboot. You cannot permanently delete the Internal EFI Shell.
To access this screen from the Main screen, select Boot Options > Delete Boot Options.
Boot Options
Delete Boot Option
Delete Boot Option Select one to Delete/Internal EFI Shell
Figure 44. Setup Utility — Delete Boot Option Screen Display
Table 37. Setup Utility — Delete Boot Option Fields
Setup Item Options Help Text Comments
Delete Boot Option Select one to Delete
Internal EFI Shell
Remove an EFI boot option from the
boot order.
If the EFI shell is deleted,
it is restored on the next
system reboot. It cannot
be permanently deleted.
5.3.2.6.3 Hard Disk Order Screen
The Hard Disk Order screen allows the user to control the hard disks.
To access this screen from the Main screen, select Boot Options > Hard Disk Order.
Boot Options
Hard Disk #1 < Available Hard Disks >
Hard Disk #2 < Available Hard Disks >
Figure 45. Setup Utility — Hard Disk Order Screen Display
Table 38. Setup Utility — Hard Disk Order Fields
Setup Item Options Help Text
Hard Disk #1 Available
Legacy devices
for this Device
group.
Set system boot order by selecting the boot
option for this position.
Hard Disk #2 Available
Legacy devices
for this Device
group.
Set system boot order by selecting the boot
option for this position.
