Overview Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
16
2.1.3 Server Board Rear I/O Layout
The following drawing shows the layout of the rear I/O components for the server boards.
Callout Description Callout Description
A System Status LED E Video
B ID LED F
NIC Port 1 (1 Gb, Default Management
Port)
USB Port 2 (top), 3 (bottom)
C Diagnostics LED’s G
NIC Port 2 (1 Gb)
USB Port 0 (top), 1 (bottom)
D Serial Port A
Figure 12. Rear I/O Layout
