Functional Architecture Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
42
3.5 PCI Subsystem
The primary I/O buses for the Intel
®
Server Board S5520HC are PCI, PCI Express* Gen1, and
PCI Express* Gen2 with six independent PCI bus segments.
The primary I/O buses for the Intel
®
Server Board S5500HCV are PCI, PCI Express* Gen1, and
PCI Express* Gen2 with five independent PCI bus segments.
PCI Express* Gen1 and Gen2 are dual-simplex point-to-point serial differential low-voltage
interconnects. A PCI Express* topology can contain a Host Bridge and several endpoints (I/O
devices). The signaling bit rate is 2.5 Gb/s one direction per lane for Gen1 and 5.0 Gb/s one
direction per lane for Gen2. Each port consists of a transmitter and receiver pair. A link between
the ports of two devices is a collection of lanes (x1, x2, x4, x8, x16, and so forth). All lanes
within a port must transmit data using the same frequency. The PCI buses comply with the PCI
Local Bus Specification, Revision 2.3.
The following tables list the characteristics of the PCI bus segments. Details about each bus
segment follow the tables.
Table 8. Intel
®
Server Board S5520HC PCI Bus Segment Characteristics
PCI Bus Segment Voltage Width Speed Type PCI I/O Card Slots
PCI32
ICH10R
5 V 32 bit 33 MHz PCI PCI Slot 1
PE1, PE2, PE3,
PE4
ICH10R PCI
Express* Ports
3.3 V x4 10 Gb/s PCI
Express*
Gen1
x4 PCI Express* Gen1 throughput to Slot
2 (x8 mechanically) and Intel
®
SAS Entry
RAID Module AXX4SASMOD slot
(Default to Slot 2, and switch to SAS
Module slot when Intel
®
SAS Entry RAID
Module AXX4SASMOD is detected)
This PCI Express* Gen1 slot is not
available when the SAS module slot is in
use and vice versa.
PE5
ICH10R PCI
Express* Port
3.3 V x1 2.5 Gb/s PCI
Express*
Gen1
x1 PCI Express* Gen1 throughput to
onboard Integrated BMC
PE1, PE2
5520 IOH PCI
Express* Ports
3.3 V x4 10 Gb/s PCI
Express*
Gen1
x4 PCI Express* Gen1 throughput to
onboard NIC (82575EB)
PE3, PE4
5520 IOH PCI
Express* Ports
3.3 V x8 40 Gb/S PCI
Express*
Gen2
x8 PCI Express* Gen2 throughput to Slot
6 (x16 mechanically)
PE5, PE6
5520 IOH PCI
Express* Ports
3.3 V x8 40 Gb/S PCI
Express*
Gen2
x8 PCI Express* Gen2 throughput to Slot
5 (x8 mechanically)
PE7, PE8
5520 IOH PCI
Express* Ports
3.3 V x8 40 Gb/S PCI
Express*
Gen2
x8 PCI Express* Gen2 throughput to Slot
4 (x8 mechanically)
PE9, PE10
5520 IOH PCI
Express* Ports
3.3 V x8 40 Gb/S PCI
Express*
Gen2
x8 PCI Express* Gen2 throughput to Slot
3 (x8 mechanically)
