Functional Architecture Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS
Revision 1.8
Intel order number E39529-013
50
Table 14. Video Modes
2D Mode
2D Video Mode Support
8 bpp 16 bpp 24 bpp 32 bpp
640 x 480
Supported Supported Supported Supported
60, 72, 75, 85 60, 72, 75, 85 60, 72, 75, 85 60, 72, 75, 85
Refresh Rate
(Hz)
800 x 600
Supported Supported Supported Supported
56, 60, 72, 75, 85 56, 60, 72, 75, 85 56, 60, 72, 75, 85 56, 60, 72, 75, 85
Refresh Rate
(Hz)
1024 x 768
Supported Supported Supported Supported
60, 70, 75, 85 60, 70, 75, 85 60, 70, 75, 85 60, 70, 75, 85
Refresh Rate
(Hz)
1152 x 864
Supported Supported Supported N/A
75 75 75 N/A
Refresh Rate
(Hz)
1280 x 1024
Supported Supported Supported N/A
60, 75, 85 60, 75, 85 60 NA
Refresh Rate
(Hz)
1440 x 900
Supported Supported Supported N/A
60 60 60 NA
Refresh Rate
(Hz)
1600 x 1200
Supported Supported N/A N/A
60. 65, 70, 75, 85 60. 65, 70 N/A N/A
Refresh Rate
(Hz)
3.11.2 Dual Video
The BIOS supports single- and dual-video modes. The dual-video mode is enabled by default.
• In single mode, the onboard video controller is disabled when an add-in video card is
detected.
• In dual mode (enable “Dual Monitor Video” in the BIOS setup), the onboard video
controller is enabled and is the primary video device. The add-in video card is allocated
resources and considered the secondary video device.
• The BIOS Setup utility provides options on Advanced | PCI Configuration Screen to
configure the feature as follows:
Onboard Video
Enabled
(default)
Disabled
Dual Monitor Video
Enabled Shaded if onboard video is set to "Disabled"
Disabled
(Default)
