Intel® Server Boards S5520HC, S5500HCV and S5520HCT TPS Appendix F: POST Error Messages and Handling
Revision 1.8
Intel order number E39529-013
169
POST Error Beep Codes
The following table lists the POST error beep codes. Prior to system video initialization, the
BIOS uses these beep codes to inform users of error conditions. The beep code is followed by a
user-visible code on the POST Progress LED’s.
Table 87. POST Error Beep Codes
Beeps Error Message POST Progress Code Description
3 Memory error Multiple System halted because a fatal error related to the memory was
detected.
The BMC may generate beep codes upon detection of failure conditions. Beep codes are
sounded each time the problem is discovered, such as on each power-up attempt but are not
sounded continuously. Each digit in the code is represented by a sequence of beeps whose
count is equal to the digit.
Table 88. BMC Beep Codes
Code Reason for Beep Associated Sensors
1-5-2-1 CPU: Empty slot/Population error CPU sockets are populated incorrectly –
CPU1 must be populated before CPU2.
1-5-4-2 Power fault: DC power unexpectedly lost (power good
dropout).
Power unit – power unit failure offset.
1-5-4-4 Power control fault (power good assertion timeout). Power unit – soft power control failure offset.
