Intel® Server Boards S5520HC, S5500HCV, and S5520HCT TPS BIOS Setup Utility
Revision 1.8
Intel order number E39529-013
85
5.3.2.2.3 Mass Storage Controller Screen
The Mass Storage screen allows the user to configure the SATA/SAS controller when it is
present on the baseboard module card of an Intel system.
To access this screen from the Main menu, select Advanced > Mass Storage.
Advanced
Mass Storage Controller Configuration
Intel
®
SAS Entry RAID Module Enabled/Disabled
Configure Intel
®
SAS Entry RAID Module IT/IR RAID/Intel
®
ESRTII
Onboard SATA Controller Enabled/Disabled
Configure SATA Mode ENHANCED/COMPATIBILITY/AHCI/SW RAID
► SATA Port 0 Not Installed/<Drive Info.>
► SATA Port 1 Not Installed/<Drive Info.>
► SATA Port 2 Not Installed/<Drive Info.>
► SATA Port 3 Not Installed/<Drive Info.>
► SATA Port 4 Not Installed/<Drive Info.>
► SATA Port 5 Not Installed/<Drive Info.>
Figure 33. Setup Utility — Mass Storage Controller Configuration Screen Display
