TECHNICAL DATA - CHASSIS 164
17TECHNICAL DATA - CHASSIS
Frame Lattice frame made of chrome molybdenum steel tubing, powder-
coated
Fork WPSuspension Up Side Down 4860 ROMA
Shock absorber WPSuspension4618 with Pro‑Lever deflector
Suspension travel
front 275mm (10.83in)
Rear 265mm (10.43in)
Brake system
front Disc brake with radially screwed four-piston brake caliper, floating
brake disc
Rear Disc brake with single-piston brake caliper, floating
Diameter of brake discs
front 320mm (12.6in)
Rear 240mm (9.45in)
Wear limit of brake discs
front 4.0mm (0.157in)
Rear 4.5mm (0.177in)
Tire air pressure, Solo
front 2.0bar (29psi)
Rear 2.0bar (29psi)
Tire air pressure with passenger / fully loaded
front 2.0bar (29psi)
Rear 2.2bar (32psi)
Rear wheel gearing 16:42
Chain 5/8x1/4” X‑ring

KTM 690 SMC Specifications

General

Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Transmission	6-speed
Lubrication	Forced oil lubrication with 2 oil pumps
Clutch	APTC slipper clutch, hydraulically actuated
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Tires Front	120/70 ZR 17
Tires Rear	160/60 ZR 17
Steering Head Angle	63.5°
Seat Height	890 mm
Engine Type	1-cylinder, 4-stroke engine
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Front Brake	Brembo four piston radial caliper, 320 mm disc
Rear Brake	Brembo single piston caliper, 240 mm disc
Wheels Front	3.50 x 17"
Wheels Rear	5.00 x 17"
Fuel Capacity	13.5 l
Power	55 kW (74 hp)
Wheelbase	1, 480 mm ± 15 mm
