TECHNICAL DATA / FORK 167
18TECHNICAL DATA / FORK
Fork part number 14.18.7D.12
Fork WPSuspension Up Side Down 4860 ROMA
Compression damping
Comfort 20clicks
Standard 15clicks
Sport 10clicks
full payload 10clicks
Rebound damping
Comfort 15clicks
Standard 10clicks
Sport 5clicks
full payload 5clicks
Spring length with preload spacer(s) 480mm (18.9in)
Spring rate
Weight of rider: 65… 75kg (143… 165lb.) 5.0N/mm (28.6lb/in)
Weight of rider: 75… 85kg (165… 187lb.) 5.2N/mm (29.7lb/in)
Weight of rider: 85… 95kg (187… 209lb.) 5.4N/mm (30.8lb/in)
Air chamber length 100±20mm (3.94±0.79in)
Fork length 915mm (36.02in)
Fork oil ( S. 174) SAE 5

KTM 690 SMC Specifications

General

Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Transmission	6-speed
Lubrication	Forced oil lubrication with 2 oil pumps
Clutch	APTC slipper clutch, hydraulically actuated
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Tires Front	120/70 ZR 17
Tires Rear	160/60 ZR 17
Steering Head Angle	63.5°
Seat Height	890 mm
Engine Type	1-cylinder, 4-stroke engine
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Front Brake	Brembo four piston radial caliper, 320 mm disc
Rear Brake	Brembo single piston caliper, 240 mm disc
Wheels Front	3.50 x 17"
Wheels Rear	5.00 x 17"
Fuel Capacity	13.5 l
Power	55 kW (74 hp)
Wheelbase	1, 480 mm ± 15 mm
