TECHNICAL DATA - SHOCK ABSORBER 168
19TECHNICAL DATA - SHOCK ABSORBER
Shock absorber part number 15.18.7D.12
Shock absorber WPSuspension4618 with Pro‑Lever deflector
Compression damping, high-speed
Comfort 1.5turns
Standard 1turn
Sport 0.5turn
full payload 0.5turn
Compression damping, low-speed
Comfort 20clicks
Standard 15clicks
Sport 10clicks
full payload 10clicks
Rebound damping
Comfort 20clicks
Standard 15clicks
Sport 10clicks
full payload 10clicks
Spring preload 18mm (0.71in)
Spring rate
Weight of rider: 65… 75kg (143… 165lb.) 80N/mm (457lb/in)
Weight of rider: 75… 85kg (165… 187lb.) 85N/mm (485lb/in)
Weight of rider: 85… 95kg (187… 209lb.) 90N/mm (514lb/in)
Spring length 220mm (8.66in)
Gas pressure 10bar (145psi)

KTM 690 SMC Specifications

General

Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Transmission	6-speed
Lubrication	Forced oil lubrication with 2 oil pumps
Clutch	APTC slipper clutch, hydraulically actuated
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Tires Front	120/70 ZR 17
Tires Rear	160/60 ZR 17
Steering Head Angle	63.5°
Seat Height	890 mm
Engine Type	1-cylinder, 4-stroke engine
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Front Brake	Brembo four piston radial caliper, 320 mm disc
Rear Brake	Brembo single piston caliper, 240 mm disc
Wheels Front	3.50 x 17"
Wheels Rear	5.00 x 17"
Fuel Capacity	13.5 l
Power	55 kW (74 hp)
Wheelbase	1, 480 mm ± 15 mm
