KTM 690 SMC User Manual

GREASING AND SERVICE TABLE 59
8GREASING AND SERVICE TABLE
8.1
Important maintenance work to be carried out by an authorized KTM workshop.
K10N K50A K100A J1A J2A
Engine
Change engine oil and oil filter, clean oil screens.x ( S. 140)
• • • • •
Check and adjust valve clearance.x
• •
Check engine mounting screws for tightness. • • • • •
Replace spark plug. •
Check engine bolts accessible from outside for tightness. • • • • •
Fuel injection
Check connection boots for cracks and leakage.x
• • •
Read out the error memory with a KTM diagnostic tool.x
• • • • •
Check fuel hoses, SLS hoses and vent hoses for damage, correct fit-
ting and leaks.x
• • • • •
Clean, check and grease the O-ring of the fuel hose connection.x
• • • •
Check the cable harness of the throttle valve body for damage and cor-
rect positioning.x
• • •
Attachments Check the cooling system for leakage. • • • • •
Check the antifreeze and coolant level. ( S. 130) • • • • •
Check the functioning of the radiator fan.x
• • • • •
Check the exhaust system for leaks and correct fitting and check that
the exhaust holders are tight.x
• • • • •
Check Bowden cables for damage, smooth operation, routing without
sharp bends and setting.
• • • • •
Check/correct the fluid level of the hydraulic clutch. ( S. 137) • • • •
Check air filter and change if necessary. Clean the air filter box.x
• • • •
Check cables for damage and routing without sharp bends.x
• • • • •
Check the headlamp setting. ( S. 126) • • • • •

KTM 690 SMC Specifications

General

Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Transmission	6-speed
Lubrication	Forced oil lubrication with 2 oil pumps
Clutch	APTC slipper clutch, hydraulically actuated
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Tires Front	120/70 ZR 17
Tires Rear	160/60 ZR 17
Steering Head Angle	63.5°
Seat Height	890 mm
Engine Type	1-cylinder, 4-stroke engine
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Front Brake	Brembo four piston radial caliper, 320 mm disc
Rear Brake	Brembo single piston caliper, 240 mm disc
Wheels Front	3.50 x 17"
Wheels Rear	5.00 x 17"
Fuel Capacity	13.5 l
Power	55 kW (74 hp)
Wheelbase	1, 480 mm ± 15 mm
