TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 170

20TECHNICAL DATA - CHASSIS TIGHTENING TORQUES

Spoke nipple, front wheel M4,5 4Nm (3lbfft) –

Spoke nipple, rear wheel M5 4Nm (3lbfft) –

Remaining screws, chassis M5 4Nm (3lbfft) –

Screw, exhaust heat shield M5 8Nm (5.9lbfft) –

Screw, electrical holder M5 3Nm (2.2lbfft) –

Screw, footbrake pedal foothold M5 6Nm (4.4lbfft)

Loctite

243™

Screw, fuel pump M5 6Nm (4.4lbfft) –

Screw, fuel level indicator M5 3Nm (2.2lbfft) –

Screw, headlight mask M5 5Nm (3.7lbfft) –

Screw, side stand switch M5 3Nm (2.2lbfft) –

Screw, side cover M5 2Nm (1.5lbfft) –

Screw, seat lock M5 3Nm (2.2lbfft)

Loctite

222

Screw, starter cable on starter M5 3Nm (2.2lbfft) –

Nut, foot brake cylinder screw M6 10Nm (7.4lbfft) –

Remaining nuts, chassis M6 15Nm (11.1lbfft) –

Remaining screws on fuel tank M6 6Nm (4.4lbfft) –

Remaining screws, chassis M6 10Nm (7.4lbfft) –

Screw, brake fluid reservoir of rear brake M6 5Nm (3.7lbfft) –

Screw, rear brake disc M6 14Nm (10.3lbfft)

Loctite

243™

Screw, front brake disc M6 14Nm (10.3lbfft)

Loctite

243™

Screw, license plate holder, bottom M6 8Nm (5.9lbfft) –

Screw, ball joint of push rod on foot-

brake cylinder

M6 10Nm (7.4lbfft)

Loctite

243™

Screw, radiator bracket M6 5Nm (3.7lbfft) –
