KTM 690 SMC User Manual

TECHNICAL DATA - CHASSIS 165
Steering head angle 63°
Wheelbase 1,480±15mm (58.27±0.59in)
Seat height unloaded 900mm (35.43in)
Ground clearance unloaded 290mm (11.42in)
Weight without fuel 139.5kg (307.5lb.)
Maximum permissible front axle load 150kg (331lb.)
Maximum permissible rear axle load 200kg (441lb.)
Maximum permissible overall weight 350kg (772lb.)
Battery YTZ10S Battery voltage: 12V
Nominal capacity: 8.6Ah
maintenance-free
Fuse 58011109130 30A
Fuse 75011088015 15A
Fuse 75011088010 10A
17.1Lighting equipment
Headlight H4/P43t 12V
60/55W
Parking light W2,1x9,5d 12V
5W
Instrument lights and indicator lamps LED
Flasher light BAU15s 12V
10W
Brake / tail light BA15d 12V
21/5W

KTM 690 SMC Specifications

General

Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Transmission	6-speed
Lubrication	Forced oil lubrication with 2 oil pumps
Clutch	APTC slipper clutch, hydraulically actuated
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Tires Front	120/70 ZR 17
Tires Rear	160/60 ZR 17
Steering Head Angle	63.5°
Seat Height	890 mm
Engine Type	1-cylinder, 4-stroke engine
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Front Brake	Brembo four piston radial caliper, 320 mm disc
Rear Brake	Brembo single piston caliper, 240 mm disc
Wheels Front	3.50 x 17"
Wheels Rear	5.00 x 17"
Fuel Capacity	13.5 l
Power	55 kW (74 hp)
Wheelbase	1, 480 mm ± 15 mm
