TRANSMISSION
B1220, B1620, B1820, WSM
3-S11
(EU)
(2) Separating Center Frame and Transmission
Draining Transmission Fluid
1. Place an oil pan underneath the transmission case, and remove
the drain plugs (1).
2. Drain the transmission fluid.
3. Reinstall the drain plug.
(When refilling)
• Fill new oil from filling port after removing the filling plug (2) up
to the upper notch on the dipstick (3).
• After running the engine for few minutes, stop it and check the
oil level again, if low, add oil prescribed level.
• Use only multi-grade transmission oil. Use of other oils
may damage the transmission or hydraulic system. Refer
to "LUBRICANTS, FUEL AND COOLANT" (See page G-9).
• Never work the tractor immediately after changing the
transmission oil. Keep the engine at medium speed for a
few minutes to prevent damage to the transmission.
• Do not mix different brands oil together.
9Y1210272ENS0004US0
Battery Negative Cable
1. Open the bonnet (1) and remove the front grille (3).
2. Disconnect the battery negative cable (2).
• When disconnecting the battery cables, disconnect the
grounding cable first. When connecting, the positive cable
first.
9Y1210272TRS0006US0
Transmission fluid Capacity
10.5 L
2.77 U.S.gals
2.31 Imp.gals
(1) Drain Plug
(2) Filling Plug
(3) Dipstick
[A] With Mid-PTO Model
[B] Without Mid-PTO Model
(A) Proper Oil Level
(1) Bonnet
(2) Battery Negative Cable
(3) Front Grille
