GENERAL
B1220, B1620, B1820, WSM
G-50
(EU)
[2] TREAD ADJUSTMENT
CAUTION
• Support tractor securely on stands before removing a wheel.
• Never operate tractor with a loose rim, wheel or axle.
IMPORTANT
• Always attach tires as shown in the figure.
• If not attached as the figure, transmission parts may be damaged.
• Do not use tires larger than specified.
9Y1210272GEG0046US0
(1) Front Wheels
Front wheel cannot be adjusted.
IMPORTANT
• Do not turn front discs to obtain wider tread. In setting up the front wheels, make sure that the inflation
valve stem of the tires face outward.
9Y1210272GEG0047US0
4.5 - 10 Farm 5 - 12 Farm 6 - 12B Farm
20 × 8.00-10 Turf
20.5 × 8.00-10 Turf
778 mm
(30.6 in.)
767 mm
(30.2 in.)
786 mm
(30.9 in.)
798 mm
(31.4 in.)
A : Tread
KiSC issued 07, 2011 A

Kubota B1620 Specifications

General

Engine Type	Diesel
Cylinders	3
Fuel Type	Diesel
Hydraulic System Type	Open center
Drive	4WD
3-Point Hitch Category	Category I
