10. A.C. GENERATOR/STARTER CLUTCH
10-4
PEOPL E 25 0
Remove the oil through and spring.
FLYWHEEL REMOVAL
Hold the flywheel with a flywheel holder and
remove the flywheel nut and washer.
Flywheel holder E021
Remove the flywheel with a flywheel puller.
Flywheel puller E003
STARTER CLUTCH
REMOVAL
Remove the starter driven gear.
Flywheel
Nut
Flywheel Holder
Starter Driven Gear
Flywheel Puller
Oil Through
Spring
Special
Special
