KYMCO PEOPLE 250 Service Manual

6. CYLINDER HEAD/VALVES
6-8
PEOPL E 25 0
INSPECTION
CYLINDER HEAD
Check the spark plug hole and valve areas for
cracks.
Check the cylinder head for warpage with a
straight edge and feeler gauge.
Service Limit: 0.05mm repair or replace if
over
VALVE SPRING FREE LENGTH
Measure the free length of the inner and outer
valve springs.
Service Limits:
Inner (IN, EX) : 29.5mm replace if below
Outer (IN, EX): 39.5mm replace if below
VALVE /VALVE GUIDE
Inspect each valve for bending, burning,
scratches or abnormal stem wear.
Check valve movement in the guide.
Measure each valve stem O.D.
Service Limits: IN: 4.925mm replace if
below
EX: 4.915mm replace if
below
CYLINDER HEAD ASSEMBLY
Install the valve spring seats and stem seals.
Lubricate each valve stem with engine oil and
insert the valves into the valve guides.
Be sure to install new valve stem seals.
Valve spring compressor E040
Straight Edge
Feeler Gauge
Valve Spring Compressor
Special

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
