KYMCO PEOPLE 250 Service Manual

8. DRIVE AND DRIVEN PULLEYS/
V-BELT
8-5
PEOPL E 25 0
MOVABLE DRIVE FACE
ASSEMBLY
Remove the pulley face, clutch outer, driven
pulley and belt. (
!
8-4))
Remove the movable drive face assembly.
Remove the drive pulley collar.
DISASSEMBLY
Remove the ramp plate.
Remove the weight rollers.
INSPECTION
Check each weight roller for wear or damage.
Measure each weight roller O.D.
Service Limit: 22.00mm replace if below
Drive Pulley Collar
Ramp Plate
Weight Roller
Movable Drive Face Assembly

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
