KYMCO PEOPLE 250 Service Manual

8. DRIVE AND DRIVEN PULLEYS/
V-BELT
8-3
PEOPL E 25 0
LEFT CRANKCASE COVER
REMOVAL
Remove the met-in box and carrier. (
!2-6
)
Remove the body cover, center cover and rear
fender A together. (
!2-6
)
Disconnect the belt air tube from the frame
Remove the left crankcase cover bolts and left
crankcase covers.
Remove the seal rubber and dowel pins.
INSTALLATION
Install the dowel pins and the seal rubber.
Install the left crankcase cover.
Install and tighten the left crankcase cover
bolts.
Left Crankcase Cover
Air Tube
Bolts
Dowel Pins
Seal Rubber
Left Crankcase Cover
Left Crankcase Cover
Bolts

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
