KYMCO PEOPLE 250 Service Manual

2. EXHAUST MUFFLER/FRAME COVERS
2-3
PEOPL E 25 0
FRAME COVERS REMOVAL
RIGHT AND LEFT BACK MIRROR
REMOVAL
Loosen the nut on the back mirror.
Remove the back mirror.
HANDLEBAR FRONT COVER
REMOVAL
Remove one bolt on the handlebar front
cover.
Remove the four screws attaching handlebar
rear cover to separate from handlebar rear
cover.
Disconnect all of the wire connectors,
couplers.
Remove handlebar front cover.
Nuts
Bolt
Screws
Wire Connectors

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
