KYMCO PEOPLE 250 Service Manual

16. BATTERY/CHARGING SYSTEM
16-2
PEOPL E 25 0
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• The battery can be charged and discharged repeatedly. If a discharged battery is not used for a
long time, its service life will be shortened. Generally, the capacity of a battery will decrease after
it is used for 2_ 3 years. A capacity-decreased battery will resume its voltage after it is
recharged but its voltage decreases suddenly and then increases when a load is added.
• When a battery is overcharged, some symptoms can be found. If there is a short circuit inside the
battery, no voltage is produced on the battery terminals. If the rectifier won‘t operate, the
voltage will become too high and shorten the battery service life.
• If a battery is not used for a long time, it will discharge by itself and should be recharged every 3
months.
• A new battery filled with electrolyte will generate voltage within a certain time and it should be
recharged when the capacity is insufficient. Recharging a new battery will prolong its service life.
• Inspect the charging system according to the sequence specified in the Troubleshooting.
• Do not disconnect and soon reconnect the power of any electrical equipment because the electronic
parts in the regulator/rectifier will be damaged. Turn off the ignition switch before operation.
• It is not necessary to check the MF battery electrolyte or fill with distilled water.
• Check the load of the whole charging system.
• Do not quick charge the battery. Quick charging should only be done in an emergency.
• Remove the battery from the motorcycle for charging.
• When replacing the battery, do not use a traditional battery.
• When charging, check the voltage with an electric tester.
SPECIFICATIONS
Item
Standard
Capacity
12V10AH
Voltage
Fully charged
13.2V
Battery
(20℃ )
Undercharged
12.3V
Charging current
STD: 1.2 A Quick: 5.0A
Charging time
STD: 5-10hr Quick:60min
Capacity
180W/5000rpm
A.C. Generator
Charging coil resistance (20℃ )
Yellow_ Yellow
1.6_ 2.5W
Charging rpm
1300rpm max (14V)
Charging performance
9A min/5000rpm
Regulator/Rectifier
Limit voltage
14.5±0.5V
TESTING INSTRUMENTS TORQUE VALUES
Ammeter Pulser coil bolt 4.9N-m
Electric tester: YF-3501 Coil lock bolt 8.8N-m
Tachometer Flywheel nut 58.8N-m
The battery electrolyte (sulfuric acid) is poisonous and may seriously damage the skin and
eyes. Avoid contact with skin, eyes, or clothing. In case of contact, flush with water and get
prompt medical attention
＊

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
