KYMCO PEOPLE 250 Service Manual

14.STEERING HANDLEBAR/FRONT WHEEL/FRONT
BRAKE/FRONT SHOCK ABSORBER/FRONT FORK
14-5
PEOPL E 25 0
Lubricate the throttle grip front end with
grease and then install the throttle grip.
Connect the throttle cable to the throttle grip.
Install the right and left handlebar switches
and tighten the screws.
Install the front and rear brake master
cylinders.
FRONT WHEEL
REMOVAL
Remove the two bolts from the left front
absorber.
Remove the screw from the speedometer gear
unit then disconnect the speed wire from the
speedometer gear unit.
Remove the front axle to pull out the axle.
Remove the front wheel and the speedometer
gear unit.
INSPECTION
AXLE RUNOUT
Set the axle in V blocks and measure the
runout using a dial gauge.
The actual runout is _ of the total indicator
reading.
Service Limit: 0.2mm replace if over
Bolt
Throttle Grip
Throttle Cable
• Adjust the throttle grip free play to the
specified range of 2_ 6mm.
＊
• Install the brake master cylinders by
aligning the index marks.
＊
Brake Master Cylinder
Axle
Speedometer Gear Unit
Bolts
Screw

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
