KYMCO PEOPLE 250 Service Manual

3. INSPECTION/ADJUSTMENT
3-6
PEOPL E 25 0
VALVE CLEARANCE
Remove the met-in box and center cover.
Disconnect oil vapor recovery tube and
secondary air cleaner fresh air outlet hose
from cylinder head cover.
Remove two lower bolts and two nuts on the
cylinder head cover.
Place the scooter on its side stand and load a
person on the rear carrier for remove the two
upper bolts on the cylinder head cover and
remove cylinder head cover.
Turn the A.C. generator flywheel to the top
dead center (TDC) on the compression stroke
so that the “T” mark on the flywheel aligns
with the index mark on the left crankcase
cover.
Inspect and adjust valve clearance.
Valve Clearance: IN: 0.1mm
EX: 0.1mm
Loosen the lock nut and adjust by turning the
adjusting nut
Valve Adjuster E036
CARBURETOR IDLE SPEED
Lift up the seat and remove the inspection
cover.
Warm up the engine before this operation.
Start the engine and connect a tachometer.
Turn the throttle stop screw to obtain the
specified idle speed.
Idle Speed: 1700±100rpm
When the engine misses or run erratic, adjust
the pilot screw.
Throttle Stop Screw
Pilot Screw
Feeler Gauge
• Inspect and adjust valve clearance while
the engine is cold (below 35℃ ).
＊
• Check the valve clearance again after
the lock nut is tightened.
＊
• The engine must be warm for accurate
idle speed inspection and adjustment.
＊
Cylinder Head Cover
Upper Bolts
Top Dead Center Mark
Special
Nuts
“T” Mark
Index Mark
Lower Bolts

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
