KYMCO PEOPLE 250 Service Manual

5. ENGINE REMOVAL/INSTALLATION
5-5
PEOPL E 25 0
Remove the engine mounting bolt and pull out
the engine.
ENGINE INSTALLATION
Reverse the “REMOVAL” procedures.
ENGINE HANGER REMOVAL
Remove met-in box and carrier. (
!2-6
)
Remove the body cover, center cover and rear
fender A together. (
!
2-6)
Remove air cleaner. (
!
5-3)
Remove the two nuts of the right and left
step bar.
Remove the right and left step bar.
Remove the engine mounting nut and engine
hanger bolt (left side).
Remove the engine mounting bolt and engine
hanger bolt (right side).
Remove the starter motor. (
!18-3
)
Remove the engine hanger.
Engine Mounting Bolt
Nuts
Nuts
Step Bar
Step Bar
Engine Mounting Nut
Bolt
Engine Mounting Bolt
Bolt
Apply grease onto the O-rings, oil seals
and bush).
＊

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
