ENGINE OIL/OIL FILTER
Remove the oil dipstick and check the oil
level with the oil dipstick.
If the level is near the lower level, fill to the
upper level with the recommended engine oil.
OIL CHANGE
Remove the oil drain bolt located at the left
side of the engine to drain the engine oil.
After the oil has been completely drained,
install the aluminum washer and tighten the
oil drain bolt.
Torque: 14.7N-m
Pour the recommended oil through the oil
filler hole.
OIL FILTER SCREEN
Drain the engine oil.
Remove the oil filter screen cap.
Remove the oil filter screen and spring.
Check the oil filter screen for clogging or
damage and replace if necessary. Check the
filter screen O-ring for damage and replace if
necessary.
Install the oil filter screen, spring, O-ring and
filter screen cap.
Torque: 12.7N-m
Recommended Oil: SAE15W40# API: SJ
Oil Capacity:
At disassembly: 1.1 liter
At change: 0.9 liter
Start the engine and check for oil leaks. Start
the engine and let it idle for few minutes, then
recheck the oil level.
• Place the scooter upright on level
ground for engine oil level check.
• Run the engine for 2_ 3
minutes and check the oil level after the
engine is stopped for 2_ 3 minutes.
