AUTO BYSTARTER INSPECTION
/REMOVAL
AUTO BYSTARTER INSPECTION
Measure the resistance between the auto
bystarter wire terminals.
Resistance: 10W (10 minutes minimum
after stopping the engine)
If the reading is not within the limit, replace
the auto bystarter with a new one.
Connect a hose to the fuel enriching circuit of
the carburetor. Connect the auto bystarter
green/black wire to the positive (+) terminal
of a battery and black/white wire to the
negative (-) terminal. Wait 5 minutes and
blow the hose with mouth. If the passage is
blocked, the auto bystarter is normal.
Disconnect the auto bystarter from the
battery. Wait 30 minutes and blow the hose
with mouth.. If air can be blown into the
hose, the auto bystarter is normal.
AUTO BYSTARTER REMOVAL
Remove the one set plate screw and set plate
and then remove the auto bystarter from the
carburetor body.
