KYMCO PEOPLE 250 Service Manual

8. DRIVE AND DRIVEN PULLEYS/
V-BELT
8-2
PEOPL E 25 0
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• The drive pulley, clutch and driven pulley can be serviced with the engine installed.
• Avoid getting grease and oil on the drive belt and pulley faces. Remove any oil or grease from
them to minimize the slipping of drive belt and drive pulley.
SPECIFICATIONS
Item
Standard (mm)
Service Limit (mm)
Movable driven face bushing I.D.
40.000_ 40.025
40.06
Driven face collar O.D.
39.965_ 39.955
39.85
Drive belt width
23.6_ 24.4
22.0
Clutch lining thickness
3.963_ 4.037
2.0
Clutch outer I.D.
153.0_ 153.2
153.5
Weight roller O.D
22.92_ 23.08
22.0
Drive pulley collar O.D.
26.960_ 26.974
26.90
TORQUE VALUES
Drive face nut 88.2_ 98N-m
Clutch outer nut 49.0_ 58.8N-m
Clutch drive plate nut 49.0_ 58.8N-m
SPECIAL TOOLS
Universal holder Clutch spring compressor
Bearing driver Lock nut wrench, 39mm
Kick starter spring remover
TROUBLESHOOTING
Engine starts but motorcycle won‘t move Lack of power
• Worn drive belt • Worn drive belt
• Broken ramp plate • Weak driven face spring
• Worn or damaged clutch lining • Worn weight roller
• Broken driven face spring • Faulty driven face
Engine stalls or motorcycle creeps
• Broken clutch weight spring

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
