KYMCO PEOPLE 250 Service Manual

4. LUBRICATION SYSTEM
4-4
PEOPL E 25 0
OIL PUMP REMOVAL
First drain the coolant.
Remove the right crankcase cover. (
!
10-3)
Remove the A.C. generator starter driven
gear. (
!
10-3)
Remove the attaching bolt and oil separator
cover.
Pry the circlip off and remove the oil pump
driven gear, then remove the oil pump drive
chain.
Remove the two oil pump bolts to remove
the oil pump.
OIL PUMP DISASSEMBLY
Remove the screw and disassemble the oil
pump as shown.
Bolts
Oil Separator Cover
Circlip
Oil Pump Driven Gear
Oil Pump Drive chain
Oil Pump
Bolts

KYMCO PEOPLE 250 Specifications

General

Displacement	249 cc
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Front Tire	110/70-16
Rear Tire	140/70-16
Transmission	CVT
Seat Height	800 mm
Width	780 mm
