Manitowoc Grove GMK6300L-1 Maintenance Manual

Maintenance work on the carrier
7.8 Axle lines
7 - 52 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
7.8.3 Axle centre drives – Changing the oil
Oil, spare parts,
tools
1)
Additional equipment (6th driven axle line)
– Receptacle, approx. 20 ltr (5.0 gal); à p. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers or parked over an
inspection
pit.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
M 12
Gear oil in litres
(gal)
Designation
according to
DIN 51502
Specification
Classification
GROVE part no.
Axle line 1+5/6:
each 7.5 (1.9)
Axle line 5
1)
:
7.7 (2.0)
Axle lines 4:
8.0 (2.1)
C - LPF MIL-L 2105 B
API-GL-5
Viscosity:
Hyp SA
E 90
ISO - VG 220
00552891
For drive Designation Quantity GROVE part no.
12 x 6 x 12
Gasket 30 x 36 Cu DIN 7603
3 00117151
Gasket 16 x 20 Cu DIN 7603 5 00117134
12 x 8 x 12
1)
Gasket 30 x 36 Cu DIN 7603 4 00117151
Gasket 16 x 20 Cu DIN 7603 8 00117134
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable receptacles. Wipe up any
consumables tha
t escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
