Manitowoc Grove GMK6300L-1 Maintenance Manual

Maintenance work on the carrier
7.8 Axle lines
7 - 56 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
7.8.5 Final drives – Changing the oil
Oil, spare parts,
tools
1)
Additional equipment (6th driven axle line)
– Drain channel.
– Receptacle, approx. 5 ltr (1.5 gal);
à p. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
– The parking brake must be released.
M 12
Gear oil in
litres (gal)
Designation
according to
DIN 51502
Specification
Classification
GROVE part no.
for each final
drive:
4.1 (1.1)
C - LPF MIL-L 2105 B
API-GL-5
Viscosity:
Hyp SAE 90
ISO - VG 220
005528
91
For drive Designation Quantity GROVE part no.
12 x 6 x 12 Gasket 24 x 29 Cu DIN 7603 6 00117145
12 x 8 x 12
1)
Gasket 24 x 29 Cu DIN 7603 8 00117145
O
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable receptacles. Wipe up
any c
onsumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
