Maintenance work on the superstructure
8.6 Hoists
13.02.2018
Maintenance manual 3 302 719 en 8 - 43
GMK6300L-1
8.6.4 Lubricating the auxiliary hoist
Grease, spare
parts, tools
– Grease gun from the tool set.
Prerequisites – The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Lubricating
• Clean the lubricating nipple (1) and lubricate
the hoist at the lubricating nipple.
• Remove any grease that emerges.
Lubricating
grease
Designation
according to
DIN 51502
Specification
Classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
S
Risk of damage to the auxiliary hoist.
The auxiliary hoist drum bearing is not automatic
ally lubricated by the
centralised lubrication pump on the turntable.
Lubricate the auxiliary hoist drum bearing with the grease gun at the
lubricating nipple.
