Maintenance work on the carrier
7.9 Wheels
7 - 64 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
7.9.4 Changing the wheels
The wear on tyres varies depending on whether the axle
– is driven/not driven,
– is steered/not steered,
– is braked/not braked,
– and whether it is subject to more or less load.
To achieve even wear, you must swap the wheels to different positions
regularly.
This will have a positive effect on tyre life and performance.
Spare parts
and t
ools
– Torque wrench for
650 Nm
(480 lbf ft).
Prerequisites – The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Changing the
wheels
• Remove the wheels from the axles.
Only for two-piece aluminium rims
• Have a specialist workshop check the bolts on the two-piece aluminium
rims, using the appropriate special tool.
Depending on the manufacturer, there are 20 or 22 bolts visible on the outer
face of the rim. On th
e inner face of the rim there are 20 or 22 nuts. It is the
torque of these that you must have checked in a specialist workshop;
à Recognising two-piece aluminium rims, p. 7 - 65.
Designation Quantity
per wheel
GROVE part no.
Wheel nut with pressure plate
for steel rims
12 01207756
Wheel nut with pressure plate
for aluminium rims
12
7659100000
G
Risk of accidents if the procedure is not carried out correctly.
This section only shows the sequence to be followed when changing
wheels.
When removing/installing the wheels, observe all the safety instructions
and the procedure stated in the operating manual.
