Manitowoc Grove GMK6300L-1 Maintenance Manual

Maintenance work on the superstructure
8.11 Hoist ropes
13.02.2018
Maintenance manual 3 302 719 en 8 - 101
GMK6300L-1
H
Observe the hook block when unreeling.
The hook block must not rotate.
• Set the lowering limit switch; à p. 8 - 101.
• Run in the new rope with small loads so that the rope can settle on
the hoist drum.
8.11.6 Setting the lowering limit switch
A lowering limit switch is mounted both on the main hoist and on
the auxiliary hoist.
Spare parts
and t
ools
Prerequisites – A hook block must be reeved 4-fold;
à Manual de instrucciones.
– The main boom is fully raised and extended;
à Manual de instrucciones.
– The hook block is lowered until only five turns of the rope remain on
the hoist dru
m.
s
G
Risk of accidents if the lowering limit switch is set incorrectly.
After inserting a new rope, the lowering limit switch must always be reset.
In this way you avoid the lowering limit switch switching off too late or not
at all, the rope being damaged and the load being dropped.
Designation Quantity GROVE part no.
Cover gasket 2 02315305
