Maintenance work on the superstructure
8.3 Engine
8 - 14 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
8.3.3 Checking the air filter
• Start the engine. On the ECOS display, check whether the lamp (1) next to
the button (2) lights up.
• Press the button (2) once. This opens the Warning submenu.
You must change the air filter if the symbol is red.
Spare parts
and t
ools
Prerequisites – The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Replacing the
air filter
• Undo all the clamps (1) and remove
the cover (2).
• Change the filter (3).
• Replace the cover and secure it with all
the clamps.
Designation Quantity GROVE part no.
Filter 1
04183736
