Manitowoc Grove GMK6300L-1 Maintenance Manual

Lubricants and consumables
6.1 Lubricants
13.02.2018
Maintenance manual 3 302 719 en 6 - 3
GMK6300L-1
6.1.2 Lubricant applications list
Consec.
no.
Lubricant
type
Usage Filling
quantity in
litres (gal)
Mainte-
nance
interval
1
Engine oil
Diesel engine for carrier;
à p. 7 - 21 42 (11.1) Y 2
Diesel engine for superstructure; à p. 8 - 21 29 (7.6) Y 2
2
Gear oil Transmission; à p. 7 - 41 46 (12.2) Y 2
3
Gear oil
Transfer case;
à p. 7 - 46 15 (4) M 6
1. Axle line axle centre drive; à p. 7 - 52 7.5 (1.9) M 12
4. Axle line axle centre drive; à p. 7 - 52 8.0 (2.1) M 12
with 12 x 6 x 12 drive:
5. Axle line axle centre drive;
à p. 7 - 52
7.5 (1.9) M 12
with 12 x 8 x 12 drive:
5. Axle line axle centre drive;
à p. 7 - 52
7.7 (2.0) M 12
only available with 12 x 8 x 12 drive:
6. Axle line axle centre drive;
à p. 7 - 52
7.5 (1.9) M 12
6 or 8 x final drives; à p. 7 - 56 4.1 (1.1) M 12
4
Gear oil 12 x suspension struts; à p. 7 - 71 1.5 (0.4) M 1
5
Gear oil
2 x hoists;
à p. 8 - 44 7 (1.8) M 12
3 x slewing gears; à p. 8 - 50 0.9 (0.24) M 12
6
Hydraulic oil
Carrier hydraulic tank;
à p. 7 - 91 230 (61) M 12
Superstructure hydraulic tank; à p. 8 - 77 1220 (322) M 12
s
