Maintenance work on the superstructure
8.9 Hydraulic system
8 - 70 3 302 719 en Maintenance manual
GMK6300L-1
13.02.2018
8.9.6 Changing the ventilation filter
Spare parts
and tools
Prerequisites – The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
• Remove the cap (2).
• Change the filter (3) and fasten the cap.
• Reset the display by pressing the pin (1)
down.
Designation Quantity GROVE part no.
Filter 1 03319602
O
Risk of damage to the environment from filter residues
Store used hydraulic oil filter inserts in suitable receptacles and have
them disposed of properly by qualified personnel.
