Manitowoc Grove GMK6300L-1 Maintenance Manual

Maintenance work on the superstructure
8.3 Engine
13.02.2018
Maintenance manual 3 302 719 en 8 - 13
GMK6300L-1
8.3.2 Topping up the oil
Data on the prescribed oil specification; à Engine manufacturer’s
documentation
.
Oil
Prerequisites – The truck crane must be level.
– The engine must be switched off and secured against unauthorised use;
à p. 2 - 3.
Topping up the oil
• Add oil through the filler neck (1) up to
the max. mark.
• Close the filler neck with the cap.
• Put the dipstick (2) into the dipstick
tube after checking the oil level.
Engine oil in
l
i
tres (gal)
Designation
according to
DIN 51502
Specification
Classification
GROVE part no.
29 (7.6) HD - CD MIL-L 2104 C
DB 228.31/.51
SAE 5 W-30
03329588
S
Risk of damage to the engine if the oil level is too high.
Do not overfill with oil; the oil level must not be higher than the max.
mark (arrow marking). Drain off oil if necessary;
à Engine manufacturer’s
documentation
.
G
Risk of burns when the engine is hot.
During operation, the engine and add-on parts reach temperatures up to
400 °C (750 °F). Wear appropriate protective gloves and be careful not to
touch hot parts.
