Mercury 30 Service Manual

MID-SECTION - 5A-790-826148R2 MARCH 1997
Swivel Bracket Components
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 LINK ROD
2 1 SCREW (1-1/2 IN.) 240 20 27.1
3 1 WASHER
4 2 WASHER
5 2 NUT (.375-24)
6 1 PUCK-Co-pilot (NON HANDLE MODELS)
7
1 SWIVEL BRACKET ASSEMBLY (BLACK)
7
1 SWIVEL BRACKET ASSEMBLY (GRAY)
8 1 BUSHING (UPPER)
9 3 GREASE FITTING
10 1 BUSHING (LOWER)
11 1 SEAL
12 1 GREASE FITTING
13 1 CABLE ASSEMBLY
14 1 WASHER
15 1 NUT (.875-14)
16 1 COTTER PIN
17 1 PIVOT PIN-Reverse Lock
1
8
1 SCREW (M8 x 10) (HANDLE)
1
8
1 SCREW (M8 x 1.25 x 25)
19 1
BOOT-Rubber NON HANDLE
20 1 SPRING
21 1 WASHER
22 1 TILT TUBE
23 1 NUT (.875-14)
24 1 DECAL-Co-pilot
25 1 PIN (TRILOBE)
26 2 BUSHING
27 1 PIVOT PIN (UPPER)
28 1 STRAP-Tilt Stop (NON POWER TRIM)
29 1 LINK-Reverse Lock (UPPER)
30 1 LEVER-Reverse Lock
31 1 NUT
32 2 PIN-Reverse Lock
33 2 SPRING-Reverse Lock
34 1 LINK-Reverse Lock
35 1 WASHER 1/8 IN. DIA. LINK ROD
36 1 ARM-Reverse Lock
37 1 REVERSE LOCK
38 1 WASHER
39 1 NUT
34 1 LINK-Reverse Lock
35 1 WASHER 3/16 IN. DIA. LINK ROD
36 1 ARM-Reverse Lock
37 1 REVERSE LOCK
38 1 WASHER (Use where applicable)
40 2 NUT
