90-826148R2 MARCH 1997
MID-SECTION - 5B-29
Power T
rim System Removal
1.
T
ilt outboard to the full up position and support
with tilt lock pin.
a
a
-
T
ilt Lock Pin
2.
Disconnect the power trim wire harness and re-
move clamps.
a
a
-
Power T
rim Wire Harness Clamps
3.
Remove the trilobe pin.
4.
Drive out the upper pivot pin.
a
b
a
-
T
rilobe Pin
b
-
Upper Pivot Pin
5.
Remove the sacrificial anode.
a
a
-
Sacrificial Anode
