Mercury 30 Service Manual

90-826148R2 MARCH 1997 ATTACHMENTS/CONTROL LINKAGE - 7B-3
Tiller Handle
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 COVER KIT
2 1 PULLEY
3 1 CASE (Part of Ref #1)
4 1 SCREW (10-16 x 1/2” Self Tap) 20 2.3
5 1 CABLE--Throttle
6 1 CABLE--Throttle
7 1 SLEEVE--Insulation
8 2 SCREW (M8 x 1.25 Hex flange head) 16.5 22.4
9
1 COVER--Side (BLACK)
9
1 COVER--Side (GRAY)
10 1 BUSHING
1
1
1 ARM--Steering Handle (BLACK)
1
1
1 ARM--Steering Handle (GRAY)
12 1 RETAINER
13 1 SCREW (M5 x .8 x 12 Hex Flange Head) 35 4.0
14 1 SCREW (M6 x 1 x 25 Hex Head Cap)
15 1 LOCK--Throttle
16 1 SPRING
17 1 KNOBS--Throttle
18 1 TILLER TUBE
1
9
1 DECAL (TURTLE/RABBIT)
1
9
1 DECAL (SLOW/FAST)
20 1 HANDLE--Throttle
21 1 GRIP--Throttle Handle
22 1 SWITCH--Stop
23 2 SCREW (M10 x 90 Hex Head Cap) 35 47.5
24 1 TAB WASHER
25 1 CLIP--Cable Retainer
26 1 BUMPER
2
7
1 BRACKET--Tiller (BLACK)
2
7
1 BRACKET--Tiller (GRAY)
28 1 PLUG
29 1 WAVE WASHER
30 1 BUSHING
31 1 WASHER
